SHACMAN F3000 Dump Truck 8x4 380Hp EuroII Yellow domestic Front lift Tipper

SHACMAN F3000 Dump Truck 8x4 380Hp EuroII Yellow domestic Front lift Tipper

SHACMAN F3000 dump truck 8x4

heavy dump truck with warranty

380Hp EuroII front lift tipper

Lugar de origem:

Shaanxi, Xian

Marca:

SHACMAN

Certificação:

ISO 9001/CCC

Número do modelo:

F3000

Contacte-nos
Solicite um orçamento
Detalhes do produto
Modle:
SHACMAN SX3318DT366
Motor:
WEICHAI WP10.380E22
Transmissão:
10JSD180+QH50 RÁPIDO
Eixo:
Dobro-fase do HOMEM 2* 9.5T /2 *16 T, velocidade ratio-5.92
Base da roda:
1800+3575+1400 milímetros
Pneu:
12.00R20
Tanque de combustível:
300L
Embreagem:
φ430 embreagem de mola do diafragma
Entrada de ar:
Filtro de ar comum
Chassis:
850×300 ((8+7)
Suspensão:
Placas de placa multi-camada frontal /traseira 4 Placas principais + 4 parafusos em forma de U
Cabine:
parte superior lisa do Meio-comprimento
Cor:
Verde vermelho/verde de néon da montanha/azul/aguardente azuis Aurora White /Klein da estrela e da l
Destacar:

SHACMAN F3000 dump truck 8x4

,

heavy dump truck with warranty

,

380Hp EuroII front lift tipper

Termos do pagamento & do transporte
Quantidade de ordem mínima
1
Preço
negotiable
Detalhes da embalagem
Embalagem nua, com cera antes do transporte.
Tempo de entrega
45 dias úteis
Termos de pagamento
T/t, l/c
Habilidade da fonte
5000 unidades/mês
Produtos relacionados
Contacte-nos
Contato agora
Descrição do produto

SHACMAN F3000 Dump Truck 8x4 380Hp EuroII Yellow



Detailed Product Description

Model:SX3315DT366
Drive type:8x4
Engine Brand: WEICHAI
Engine Model:WP10.380E22
Engine Power/(kw/HP): 279kw / 380Hp
Gear box Brand: FAST
Gear box Model: 10JSD180+QH50



Dump Truck Parameters

Model SX3315DT366
Drive type 8x4
Weight Gross Vehicle Weight ≤90
Dimensions Wheelbase/(mm) 1800+3575+1400
Performance Maximum speed/(km/h) 45~60/80
Ground clearance >314
Engine Brand WEICHAI
Model WP10.380E22
Power/(kw/HP) 279kw / 380Hp
Maximum torque / (N.M)/rpm 1600 N·M
Displacement/(L) 9.726 L
Emission standard Euro II
Gear box Brand FAST
Model 10JSD180+QH50
Clutch Type φ430 Diaphragm spring clutch
Cooling Type Domestic heat sink
Air inlet Type Ordinary air filter
Brakes Type Drum brake
Service brake Double circuit air brake
Park brake Rear wheel spring brake
Auxiliary brake WEVB engine exhaust brake
Steering Type ZF8098 technology, circulating ball steering machine
Chassis Type Parallel trapezoidal frame with variable section
Dimensions/(mm) 850×320 (8+7+8)
Suspension Front Multi-layered leaf springs with 4 Main springs+4 U Bolts
Rear Multi-layered leaf springs with 4 Main springs+4 U Bolts
Axles Brand HANDE
Front axle 9.5T front axle MAN technology
Rear axle 16T MAN Double Reduction Drive axle with inter helix differential and differential lock, bridge speed ratio: 5.262
Tires Type 12.00R20
Fuel tank Tank capacity/(L) 300L Aluminum tank
Electrics Type 24V
Battery 165Ah Maintenance-free battery
Cab Type SHACMAN F3000 Medium-length flat cab
Equipment Hydraulic main seat, four-point hydraulic suspension cab, ordinary rearview mirror, electronically controlled automatic constant temperature air conditioner, electric window shaker, 165Ah maintenance-free Battery, SHACMAN logo, full English logo.



Detailed Image

SHACMAN F3000 Dump Truck 8x4 380Hp EuroII Yellow domestic Front lift Tipper 0







































About SHACMAN Trucks

  • Headquartered in Xi'an, Shaanxi Province, the company was formerly known as Shaanxi Automobile Manufacturing Plant, which was established in 1968. It is the main R&D and production base of heavy military vehicles in China, a large-scale full-series commercial vehicle manufacturer, and the first batch of the export base of complete vehicles and parts in China, with 25,400 employees and total assets of 73.1 billion.
  • The F3000 series benefits from the technological expertise of MAN, a globally renowned commercial vehicle manufacturer. Leveraging this collaboration, SHACMAN has integrated top-tier innovations into the F3000 series, resulting in trucks that boast both reliability and advanced features.
