Name: SHACMAN F3000 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper Truck with 300L Fuel Tank and 12.00R20 Tires
Brand: SHAAN XI HAN OCEAN CO . , LTD
SKU: F3000
Price: 1,000.00 USD
Availability: InStock

Casa > produtos > Caminhão basculante pesado >

SHACMAN F3000 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper Truck with 300L Fuel Tank and 12.00R20 Tires

300L Fuel Tank Tipper Truck

12.00R20 Tires Dump Truck

Domestic Heavy Dump Truck

Lugar de origem:

Shaanxi, Xian

Marca:

SHACMAN

Certificação:

ISO 9001/CCC

Número do modelo:

F3000

Contacte-nos

Solicite um orçamento

SHACMAN F3000 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper Truck with 300L Fuel Tank and 12.00R20 Tires

Detalhes do produto

Modle:

SX3318DV366

Motor:

WP12.430E50-WEICHAI

Transmissão:

12JSD200T-B+QH50-FAST

Eixo:

9,5T /2*16 T Duplo estágio, relação de velocidade-4,769

Base da roda:

1800+3575+1400 milímetros

Pneu:

12.00R20 (10+1)

Tanque de combustível:

300L

Embreagem:

φ430 embreagem de mola do diafragma

Entrada de ar:

Filtro de ar comum

Chassis:

850×300 ((8+7)

suspensão:

Placas de placa multi-camada frontal /traseira 4 Placas principais + 4 parafusos em forma de U

Cabine:

parte superior lisa do Meio-comprimento

Cor:

Verde vermelho/verde de néon da montanha/azul/aguardente azuis Aurora White /Klein da estrela e da l

Destacar:

300L Fuel Tank Tipper Truck

12.00R20 Tires Dump Truck

Domestic Heavy Dump Truck

Termos do pagamento & do transporte

Quantidade de ordem mínima

Preço

negotiable

Detalhes da embalagem

Embalagem nua, com cera antes do transporte.

Tempo de entrega

45 dias úteis

Termos de pagamento

T/t, l/c

Habilidade da fonte

1000 unidades/mês

Produtos relacionados

Contacte-nos

Contato agora

Descrição do produto

SHACMAN F3000 Dump Truck 8x4 430Hp EuroV Yellow Domestic Front Lift Tipper

Product Overview

The SHACMAN F3000 Dump Truck is a robust 8x4 tipper designed for heavy-duty material transportation. Featuring a 430HP EuroV compliant engine and domestic front lift mechanism, this truck combines power with environmental responsibility.

Key Specifications

Model: SX3318DV366

Drive Type: 8x4

Engine: WEICHAI WP12.430E50

Power: 316kw / 430Hp

Transmission: FAST 12JSD200T-B+QH50

Emission Standard: Euro V

Technical Specifications

Category	Specification
Weight	Gross Vehicle Weight ≤70
Dimensions	Wheelbase: 1800+3575+1400 mm
Performance	Maximum speed: 40～55/75 km/h Ground clearance: >314 mm
Engine	WEICHAI WP12.430E50 316kw / 430Hp 2050 N*M maximum torque 11.596 L displacement
Drivetrain	FAST 12JSD200T-B+QH50 gearbox φ430 Diaphragm spring clutch
Braking System	Drum brakes Double circuit air brake (Service) Rear wheel spring brake (Park) WEVB engine exhaust brake (Auxiliary)
Chassis & Suspension	Parallel trapezoidal frame (850×300(8+7) mm) Multi-layered leaf springs (Front: 4 Main+4 U Bolts, Rear: 4 Main+4 U Bolts)
Axles	HANDE 9.5T front axle (MAN technology) 16T MAN Double Reduction Drive rear axle (4.769 ratio)
Other Components	12.00R20 tires 300L Aluminum fuel tank 24V electrical system with 165Ah battery
Cab Features	F3000 Medium-length flat cab Hydraulic main seat Four-point hydraulic suspension Electronically controlled automatic AC Electric windows

Key Advantages

Robust Construction: Heavy-duty chassis and suspension system provide excellent load-bearing capacity and stability for safe transportation on rough terrain.
Eco-Friendly: Complies with strict Euro V emission standards, significantly reducing nitrogen oxides (NOx) and particulate matter (PM) emissions.
